ILL-BH-LU35
Short Description
GENERAL INFORMATIONS
Model No.ILL-BH-LU35XX Series
Product Family-Bulkhead Light
Application Area-Indoor /Outdoor
Material and Finish (Body)-Die -Cast Aluminum, Black,White
IP Level-IP65
Working temperature--20°C~50°C
Working hour-50000 Hrs (80000Hrs on request)
ELECTRICAL PARAMETERS
Input voltage-120-270 VAC, 50/60 Hz/24Vdc
Power-20W,30W
Control Type-On/ Off , Dimmable
OPTICAL PARAMETERS
Light Source-LED SMD
Color Temperature (CCT)-2700K - 6500K
Color Rendering Index (CRI)->80,>90
Beam Angle-120°
Luminous output-100lm/W ( ± 5 %)
WARRANTY
5 years Warranty
CERTIFICATES
CE
Specification
ILL-BH-LU3520
:20W- 2000lm- Ø350*H108 mm-IP65
ILL-BH-LU3530
:30W- 3000lm -Ø350*H108 mm-IP65
