ILL-SL16
Short Description
The ILL-SL0XX16 Series Adjustable Spotlight is crafted to provide pinpoint lighting with versatility and style. This adjustable spotlight allows for seamless direction control, ideal for residential and commercial applications, making it perfect for highlighting key features in any space. Whether you’re illuminating artwork, display items, or architectural features, the ILL-SL0XX16 Series ensures precise, bright lighting that elevates the ambiance and functionality of any room. With cutting-edge LED technology, this spotlight provides high brightness and excellent energy efficiency, making it suitable for decorative and functional lighting in any setting.
GENERAL INFORMATIONS
Model No.ILL-SL0XX06
Product Family- Adjustable Spot Light
Application Area-Indoor
Material and Finish (Body)-Die -Cast Aluminum, White, Black
Material and Finish (Reflector)-Not Applicable
IP Level-IP20/44
Working temperature--20°C~50°C
Working hour-50000 Hrs
ELECTRICAL PARAMETERS
Input voltage- 120-270VAC, 50/60Hz
Power- 10W,15W,20W,25W,30W,35W,45W,55W,65W
Control Type- On/Off, Dimmable
OPTICAL PARAMETERS
Light Source-LED COB
Color Temperature (CCT)-2700K-6500K
Color Rendering Index (CRI)->80,>90
Beam Angle- 15°, 24°, 36°, 60°
Luminous output-95lm/W ( ± 5 %)
WARRANTY
5 years Warranty
CERTIFICATES
CE
Specification
ILL-SL01016
:10W- 950lm- Ø88xH98- Ø80
ILL-SL01516
:15W- 1425lm- Ø88xH98- Ø80
ILL-SL02016
:20W- 1900lm- Ø88xH118- Ø80
ILL-SL02516
:25W- 2375lm- Ø88xH138- Ø80
ILL-SL03016
:30W- 2850lm- Ø108xH115- Ø100
ILL-SL03516
:35W- 3325lm- Ø108xH138- Ø100
ILL-SL04516
:45W- 4275lm- Ø138xH130- Ø130
ILL-SL05516
:55W- 5225lm- Ø138xH145- Ø130
ILL-SL06516
:65W- 6175lm- Ø138xH165- Ø130
