ILL-PL600
Short Description
Model No.ILL-PL600-XX SERIES
Product Family-LED Panel light
Application Area-Indoor
Material and Finish (Body)-Die -Cast Aluminum, White
IP Level-IP20/IP65
Working temperature--20°C~50°C
Working hour-50000 Hrs (80000Hrs on request)
ELECTRICAL PARAMETERS
Input voltage-120-270 VAC, 50/60 Hz/24Vdc
Power-36W,40W
Control Type-On/ Off , Dimmable
OPTICAL PARAMETERS
Light Source-LED SMD
Color Temperature (CCT)-2700K - 6500K
Color Rendering Index (CRI)->80,>90
Beam Angle-120°
Luminous output-100lm/W ( ± 5 %)
WARRANTY
5 years Warranty
CERTIFICATES
CE,TUV
Specification
ILL-PL600-36
:40W -4000lm -L595 xW595x H34-IP20
ILL-PL600-36
:40 W- 4800lm -L595 xW595x H34-IP20
