ILL-BH220
Short Description
GENERAL INFORMATIONS
Model No.ILL-BHXX220 Series
Product Family-Bulkhead Light
Application Area-Indoor /Outdoor
Material and Finish (Body)-Polycarbonate, White
IP Level-IP65
Working temperature--20°C~50°C
Working hour-50000 Hrs (80000Hrs on request)
ELECTRICAL PARAMETERS
Input voltage-120-270 VAC, 50/60 Hz/24Vdc
Power-12W,16W,20W
Control Type-On/ Off , Dimmable
OPTICAL PARAMETERS
Light Source-LED SMD
Color Temperature (CCT)-2700K - 6500K
Color Rendering Index (CRI)->80,>90
Beam Angle-100°
Luminous output-135lm/W ( ± 5 %)
WARRANTY
5 years Warranty
CERTIFICATES
CE
Specification
ILL-BH12220
:12W -960lm -L230 xW105xH 55-IP65
ILL-BH16220
:16W- 1440 lm-L230 xW105xH 55-IP65
