ILL-DL27
Short Description
GENERAL INFORMATIONS
Model No.ILL-DLXX27-Series
Product Family-Down Light
Application Area-Indoor
Material and Finish (Body)-Die -Cast Aluminum
Material and Finish (Reflector)-Not Applicable
IP Level-IP20/54
Working temperature--20°C~50°C
Working hour-50000 Hrs (80000Hrs on request)
ELECTRICAL PARAMETERS
Input voltage-120-270 VAC, 50/60 Hz
Power-15W,19W,22W,26W
Control Type-On/ Off , Dimmable
OPTICAL PARAMETERS
Light Source-LED SMD
Color Temperature (CCT)-2700K - 6500K
Color Rendering Index (CRI)->80,>90
Beam Angle-120°
Luminous output-120lm/W ( ± 5 %)
WARRANTY
5 years Warranty
CERTIFICATES
CE
Specification
ILL-DL152027
:15W -1800lm -Ø190xH51- Ø185-IP54
ILL-DL192527
:19W-2400lm- Ø230xH51- Ø220-IP54
ILL-DL223027
:22W-3000lm- Ø285xH60 Ø270-IP54
ILL-DL263527
:26W-3600lm- Ø305xH69 Ø290-IP54
