ILL-DL22S
Spotlight
The ILL-DL22S Series is a premium square recessed LED downlight designed for both residential and commercial applications requiring high-performance illumination with moisture protection. Featuring an elegant square bezel and IP65-rated front protection, this downlight is ideal for bathrooms, kitchens, balconies, corridors, spas, wash areas, and other damp environments.Manufactured with a high-quality die-cast aluminum body for efficient heat dissipation and long operational life, the fixture delivers uniform, glare-controlled illumination with excellent visual comfort. The modern architectural design makes it suitable for hospitality, retail, residential, and commercial lighting projects.
GENERAL INFORMATIONS
Model No.- ILL-DL22S-2 Series
Product Family- Downlight
Application Area- Indoor
Material and Finish (Body)- Die Cast Aluminium
Material and Finish (Reflector)- Not applicable
IP Level- IP65
Working Temperature- -20°C~50°C
Working Hours- 50000 Hrs
ELECTRICAL PARAMETERS
Input voltage- 120-270 VAC, 50/60 Hz
Power- Refer Selection Table
Power factor- >0.9
Control Type- On/ Off , Dimmable
OPTICAL PARAMETERS
Light Source-LED
Colour Temperature (CCT)- 2700K - 6500K
Colour Rendering Index (CRI)- >80,>90
Unified Glare Rating (UGR)- <19
Beam Angle- 60°
Luminous output
100lm/W ( ± 5 %)
SDCM- <3,<5
WARRANTY
5 years Warranty
CERTIFICATES
CE
